LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
System/Therapy PCB Assembly Diagrams and Parts Lists
Section Menu Section Contents
Back
Index
390
9
3011630-00 21300-001479 2 SPACER-PCB See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387).
3206834 21330-001448 1 A01 - PCB ASSY - SYSTEM See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387). For
cable interconnect view, see Figure 9.24
on p. 446. Repair kit see System PCBA
Repair Kit, V1 (MIN 3305431-007) (p.
501).
3207010-004 21330-001318 1 ASSY-MOUNTING, BRACKET, SYSTEM, THERAPY
PCB
See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387).
804447-27 21300-003172 1 SPACER-FOAM, SYS PCB CAPS See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387).
202305-000 21300-001052 1 COIN CELL BATTERY
Table 9.5—System/Therapy Assembly Part Numbers (Continued)
MIN CATs Qty Description Notes
