LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
System/Therapy PCB Assembly Diagrams and Parts Lists
Section Menu Section Contents
Back
Index
389
9
Table 9.5—System/Therapy Assembly Part Numbers
MIN CATs Qty Description Notes
202253-550 21300-001030 1 SCREW-PH, NYLOCK, PHIL,SS,4-40X.1.125L See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387)
202253-761 21300-001038 19 SCREW-M,CS,Z,PH, NYLOCK,4-40 X .312L See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387) and
Figure 9.9: System/Therapy PCB
assembly view 2 of 2, p. 388.
3306311 21330-001449 1 A04 - PCB ASSY - THERAPY, BIPHASIC See System/Therapy PCB Assembly
Diagrams and Parts List (p. 387) and
Figure 9.9: System/Therapy PCB
assembly view 2 of 2, p. 388. For cable
interconnect view, see Figure 9.22 on p.
444. Repair kit see Therapy PCBA
Repair Kit (MIN 3305431-008) (p.
502).
3009331-00 21300-001343 1 SHIELD EMI, THERAPY PCB See Figure 9.8: System/Therapy PCB
assembly view 1 of 2, p. 387.
3009878-002 21300-001379 1 W03 - CONN-HDR, SQUAREPIN DUAL ROW, 30 PIN See Figure 9.8: System/Therapy PCB
assembly view 1 of 2, p. 387. For cable
interconnect view, see Figure 9.43 on p.
465
3011629-00 21300-001478 1 INSERT-HEX See Figure 9.9: System/Therapy PCB
assembly view 2 of 2, p. 388.
