LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Invasive Pressure Connector Assembly (W33) Replacement
Section Menu Section Contents Back Index
356
8
Removing the Invasive Pressure Connector Assembly (W33)
To remove the invasive pressure connector assembly from the rear case (refer to Inside Rear Case Diagrams (p. 228)):
1. Disassemble the case as described in Disassembling the Case (p. 181).
2. Disconnect the invasive pressure cable (3200466-01) from the J7 connector on the system PCB (A01).
3. Remove the parameter bezel as described in Removing the Parameter Bezel (p. 311).
4. Remove the eight screws and captured washers (3207337-312) that secure the IP connectors to the parameter bezel. Remove
the IP connectors and gaskets.
5. Remove the IP connectors and gaskets. Discard the screws and gaskets.
Installing the Invasive Pressure Connector Assembly (W33)
To install the Invasive Pressure Connector Assembly into the rear case (refer to Inside Rear Case Diagrams (p. 228)):
NOTE: When installing a new invasive pressure connector, use the Invasive Pressure Connector Repair Kit (MIN
3305431-001) (p. 496).
1. Secure the IP connectors and new gaskets (3007998-00) to the parameter bezel with the eight new screws (3207337-312);
torque to 6.8 in-lb. (See Figure 9.12 on p. 394 for connector orientation.)
2. Install the parameter bezel as described in Installing the Parameter Bezel (p. 313).
3. Connect the IP connector cable (3200466-01) to the system PCB (A01) at J7.
4. Reassemble the case as described in Reassembling the Case (p. 184).
CAUTION
POSSIBLE MOISTURE LEAKAGE When installing the cable, use new gaskets to help prevent ingress of fluids.
