LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Biphasic Cable (W20) Replacement
Section Menu Section Contents Back Index
341
8
Removing the Biphasic Cable (W20)
To remove the biphasic cable (W20) from the rear case:
1. Disassemble the case as described in Disassembling the Case (p. 181).
2. Press the connector locking tab and eject the W20 cable from the A22 biphasic PCB at J106.
3. For biphasic cable (3206999) only, press the connector locking tab and eject the W20 cable from the A01 system PCB at J10.
4. Press the connector locking tab and eject the W20 cable from the A04 therapy PCB at J51.
Installing the Biphasic Cable (W20)
To install the biphasic cable (W20) into the rear case:
1. Connect the W20 cable to the A04 Therapy PCB at J51.
2. For biphasic cable (6206999) only, connect the W20 cable to the A01 System PCB at J10.
3. Connect the W20 cable to the A22 biphasic PCB at J106.
4. Reassemble the case as described in Reassembling the Case (p. 184).
