LIFEPAK 15 Monitor/Defibrillator
Service Manual
Device Description
Introduction
Section Menu Section Contents Back Index
51
3
~ Provides operator review of stored events for printout or transmission
~ Captures up to 360 minutes of continuous ECG data
~ Continuous printing of ECG data
• Patient signal monitoring
~ ECG monitoring — displays up to three ECG waveforms simultaneously
~ Pulse oximetry (SpO2) monitoring (continuous numeric and waveform display)
NOTE: SpO2 numeric display will be replaced by SpCO and/or SpMet reading if one or both parameters are above alarm
threshold.
~ Heart rate/pulse rate monitoring (continuous numeric display)
~ Noninvasive blood pressure (NIBP) monitoring (numeric display)
~ Invasive pressure (IP) monitoring (continuous numeric and waveform display)
~ Capnography (CO2 and RR) monitoring (continuous numeric and waveform display)
~ Carboxyhemoglobin (SpCO) monitoring (continuous numeric is displayed when parameter is over alarm threshold)
Note: numeric display will revert to SpO2 reading when alarm condition is canceled.
~ Methemoglobin (SpMet) monitoring (continuous numeric is displayed when parameter is over alarm threshold) Note:
numeric display will revert to SpO2 reading when alarm condition is canceled.
~ Vital Signs Trend — Vital signs can be displayed graphically for time ranges up to 8 hours.
~ ST Trend — 12-lead ECG ST measurements can be displayed graphically for time ranges up to 8 hours.
~ Temperature monitoring (numeric display). This feature is only available in V2-equivalent devices.
• 12-lead ECG capture and analysis
~ Acquires, analyzes, and automatically prints 12-lead data
• Alarms and warnings management
~ Ventricular fibrillation/ventricular tachycardia monitoring and alarm
~ Places alarm limits on patient monitoring parameters
~ Automatic alarm limit reset at operator request
~ Activates or suspends alarms and stores alarm events
~ Silences alarms for up to 15 minutes
~ Visual indicators and audible tones in alarm conditions
