Physio Control LIFEPAK 15 - Page 509

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Repair Kits
Section Menu Section Contents
Back
Index
511
9
Front Case Repair Kit (MIN 3305431-023)
Table 9.39—Front Case Repair Kit Parts List
MIN Description Notes
3207725 ASSY - ENCLOSURE, FRONT
3206724 LENS - DISPLAY
3208003 LABEL - PHYSIO-CONTROL ICON
804234 SEAL - PERIMETER, CASE
202253-764 SCREW, MACHINE, PANHEAD, NYLOK, 4-40 X
.500
202253-761 SCREW-M, CS, Z, PH, NYLOCK, 4-40 X .312L
3207361-375 SCREW, CAP SCH, TORX, 6-32 X .375L, SS
201407-069 SCREW- 6-32 X .375
202253-763 SCREW-M PH, NYLOK 4-40 X .437
3207701 SEAL—THERAPY CONNECTOR
3207367 SCREW—MACHINE, TRH, T10 TORX (R), 4-40,
SS
