Subassemblies and Wire Harnesses
See the Interconnect Diagram (Figure 9.2 on p. 370)—shows detailed assembly and cable interconnect information and provides
links to each part diagram. (p. 368).
• A09 Printer Control Keypad
• A10 Main Keypad
• A11 LCD Assembly
• A12 Printer Assembly
• A13 Transfer Relay Assembly
• A14 Inductive Resistor
• A15 Energy Storage Capacitor
• A17 Interconnect Bracket
• W07 ECG Connector Cable
• W08 System Connector Cable
• W09 Auxiliary Connector Cable
• W11 Therapy Connector Cable
• W15 Speed Dial Assembly
• W17 Speaker Assembly
• W22 SpO2 Connector Cable
• W28 CO2 Inlet Connector Cable
• W33 Invasive Pressure Cable
• W35 Temperature Cable
