LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Repair Kits
Section Menu Section Contents
Back
Index
517
9
Interface PCBA Repair Kit, V2 (MIN 3305431-029)
Table 9.45—V2 Interface PCBA Repair Kit Parts List
MIN Description Notes
3306367-000 PCB ASSY—INTERFACE, LP15 V2
3207361-375 SCREW, CAP, SCH, REC T15 TORX 6-32, 0.375L,
SS, NYLOK
3206991-003 CABLE ASSY—FLEX, SYSTEM PCB/INTERFACE
PCB
202253-761 SCREW-M, CS, Z, PH, NYLOCK, 4-40 X .312L
201407-069 SCREW, SELF-SEAL, SELF-LOCK, 6-32 X 0.375
