System PCBA Repair Kit (MIN 3305431-031)
Table 9.47—System PCBA Repair Kit Parts List
MIN Description Notes
3009878 CONNECTOR—HDR, SQUARE PIN, DUAL ROW,
24 PIN
3011630 SPACER—PCB, LP12
202253 SCREW—MACHINE, PANHEAD, NYLOK
3207337 SCREW—MACHINE, PNH, PHH, 4-40, NYLOCK,
CS, WITH WASHER
3010805 SOCKET—RETAINER CLIP
3207361 SCREW—CAP, SCH, REC T15 TORX 6-32,
0.375L, SS, NYLOK
201407 SCREW—PANHEAD, PHILLIPS, STAINLESS
STEEL, SELF-SEALING, SELF-LOCKING
3011629 INSERT—HEX, LP15
3206834 PCB ASSY—SYSTEM, LP15
3306020 INSULATOR—SYSTEM PCB, CENTER
3306021 INSULATOR—SYSTEM PCB, RIGHT
3306022 INSULATOR—SYSTEM PCB, LEFT
