Wiring
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
118
Output circuit Energy store
+DC
-DC
1
2 3
-DC +DCBR
PMCenergy SD.B PMCenergy SD.E
+RB
-RB
X8
Servo Drive
PE
X1 X1 X2
RS422 X4
[E]
Energy store:
Discharge
bridge [E]
between
terminal 1:–DC
and
terminal 2:Re-
move BR.
