Technical details PMCprotego D.72
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
204
9 Technical details PMCprotego D.72
General
Approvals CE, EAC (Eurasian), TÜV, UL Listed
Electrical data
Supply voltage
Voltage 208 - 480 V
Voltage 3 x 208…3 x 480 V
Kind AC
Kind AC
Voltage tolerance -10 %/+10 %
Frequency range AC 50 - 60 Hz
Supply voltage
for Supply
Voltage 24 V
Kind DC
Tolerance
With brake +15 %
Without brake +15 %
Max. current consumption
With brake 5 A
Without brake 2 A
Current range, brake 0,15 - 3 A
Power element
Power consumption at S1 operation 50 kVA
Max. switch-on frequency 30/h
Continuous output current at 3 x 208 VAC 72 A
Continuous output current at 3 x 230 VAC 72 A
Continuous output current at 3 x 400 VAC 72 A
Continuous output current at 3 x 480 VAC 72 A
Peak output current for 2 s 140 A
Peak output current for 5 s 140 A
Tolerance -3 %/+3 %
Min. winding inductance of the motor
at 3 x 208 V AC 0,26 mH
at 3 x 230 V AC 0,29 mH
at 3 x 400 V AC 0,51 mH
at 3 x 480 V AC 0,61 mH
Voltage rise with open terminals
at 3 x 208 V AC 2,1 kV/µs
at 3 x 230 V AC 2,3 kV/µs
at 3 x 400 V AC 4 kV/µs
at 3 x 480 V AC 4,8 kV/µs
