Procedure:
1. Switch off the 24V supply to the servo amplifier.
2. Insert the SD card into the card slot in the servo amplifier.
3. Keep both operator keys on the servo amplifier pressed down.
4. Switch on the 24V supply to the servo amplifier.
5. Release the keys when "---" appears on the display.
The card cannot be accessed when "CCC" is displayed.
6. Press both operator keys again and then release.
– The firmware update for the servo amplifier is started.
– The file default.bin or default.s19 is loaded.
– Display: Counts from 0 to 100, stops at 100 and then counts from 100 to 0.
– The servo amplifier is restarted. The parameter file default.par is loaded.
7.4 LEDs and keys
The servo amplifier has a 3-digit LED display for status, error and warning messages.
The two keys can be used to navigate the menus and also to enter numerical values for
setting parameters.
7.4.1 Key functions
The keys have the following functions:
Key Description
Press once: move up one menu item, in-
crease number by one
Press twice in quick succession: increase
number by ten
Press once: move down one menu item,
decrease number by one
Press twice in quick succession: De-
crease the number by ten
Hold down right-hand button and then
press left-hand button: enter numbers,
confirm entry
