Wiring
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
144
6.7.5.11 SinCos encoder with Hall encoder
Under “Connection cables”, please note the requirements for the:
} Cable cross sections
} Insulation material
If the cable length is >25m, please speak to our Customer Support.
Connector X1 Pin Designation Description
1
8
9
15
1 B- Cosine -
2 0 V Supply voltage 0 V
3 A- Sine-
4 Up Supply voltage
5 NI+ Zero pulse +
6 Hall-U Hall-U
7 ϑ Thermal switch (+)
8 Hall-V Hall-V
9 B+. Cosine +
10 Sense 0 V Supply voltage 0 V
11 A+ Sine +
12 Sense Us Supply voltage
13 NI- Zero pulse -
14 ϑ Thermal switch (-)
15 Hall-W Hall-W
Connector pin assignment
