Installation
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
95
7. Insert expansion card 8. Tighten screws
5.5.2 Expansion cards for slot 2
The following expansion cards are available for slot 2:
} PMC expansion card PosI/O
} PMC expansion card PosI/O-AIO
} Fan controller (available only on request, cannot be retrofitted)
The procedure for incorporating the expan-
sion card into slot 2 is similar to that de-
scribed for slot 1.
Remove the front membrane.
Lever out the cover plate beneath the film.
Insert the expansion card into the slot.
Fasten the front plate of the expansion card
using the screws provided.
