Commissioning
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
193
The diagram below illustrates the function of the keys and LEDs.
Fig.: Key functions
7.4.2 Status indicator
Status
to Station address
The amended address is saved
automatically on exit.
Fig.: Status indicator
