Safety characteristic data
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
208
10 Safety characteristic data
NOTICE
You must comply with the safety characteristic data in order to achieve the
required safety level for your plant/machine.
Operating
mode
EN ISO
13849-1:
2015
PL
EN ISO
13849-1:
2015
Category
EN62061
SIL CL
EN62061
PFH
D
[1/h]
IEC 61511
SIL
IEC 61511
PFD
EN ISO
13849-1:
2015
T
M
[year]
STO 1/2, 2-
ch. with
feedback
loop PL e Cat. 4 SIL CL 3 1,38E-09 SIL 3 2,39E-06 20
STO1, 1-ch.
without feed-
back loop PL d Cat. 2 SIL CL 2 7,05E-08 SIL 2 6,09E-03 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
INFORMATION
A safety function's SIL/PL values are not identical to the SIL/PL values of
the units that are used and may be different. We recommend that you use
the PAScal software tool to calculate the safety function's SIL/PL values.
