Wiring
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
154
Input circuit Incremental encoder 24 V
with Hall encoder
X3: 100 kHz
X1: 350 kHz
ROD (AquadB) + Hall
Thermal switch in the motor
is connected to X1 or X2
Shielded
Connection
