Pilz PMCprotego D.48 User Manual

Function Description
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
52
Configura-
tion Location Parameter
Commut-
ation
Speed reg-
ulator
Position
control-
ler
Electronic
Gearing
Two en-
coders
(external
control)
In the mo-
tor
FBTYPE x x x
External GEARMODE x
Three en-
coders
(position
and control
external)
In the mo-
tor
FBTYPE x x
External EXTPOS x
External GEARMODE x
A detailed description of the parameters is available in the commissioning software's online
help.
The PMCprotegoD supports all standard encoder types.
NOTICE
Select the correct encoder (FBTYPE) in the commissioning software
tool
In the commissioning software tool PASmotion you must select the correct
encoder (FBTYPE). Selecting the wrong encoder can lead to the destruction
of the connected encoder (caused by the wrong supply voltage).
The table below provides an overview of the supported encoder types and their corres-
ponding parameters and connectors.
Feedback types with one-cable connection (power and feedback in one cable)
Hiperface DSL
Hybrid cable
