Planmeca Compact I User Manual

Chapter F - ADJUSTMENTS
Planmeca Compact i F-33
WMS OPERATION
Technical Manual
Cup fill is used, no need to fill bottle.
City Water Bottled Water
Cup fill (water bottle full) Cup fill (water bottle full)
V1 c V1 c
V2 c V2 c
V5 o V5 o
V6 c V6 c
Pump not running Pump not running
Display PCI Display PCI
Cup fill is used and at same time bottle is filled.
City Water Bottled Water
Cup fill (water level below upper sensor) Cup fill (water level below upper sensor)
V1 o V1 c
V2 o V2 c
V5 o V5 o
V6 c V6 c
Pump running Pump not running
Display PCI Display PCI
Cup fill is used and at the same time bottle is filled. In city water mode automatic cup fill does
not work.
Automatic cup fill = cup fill key pressed once
Manual cup fill = cup fill key pressed continuously
City Water Bottled Water
Cup fill (water level below lower sensor) Cup fill (water level below lower sensor)
Automatic cup fill Manual cup fill Automatic cup fill Manual cup fill
V1 ooV1 cc
V2 ooV2 cc
V5 coV5 oo
V6 ccV6 cc
Pump running running Pump not running not running
Display He 60 He 60 Display He 61 He 61

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
