Chapter F - ADJUSTMENTS
F-36 Planmeca Compact i
WMS OPERATION
Technical Manual
WCS is started with chip blow key and the bottle has to be filled with cleaning agent. After that
the feeding cycle starts.
Cleaning agent is fed to instruments
City Water Bottled Water
SW1 off SW1 on
Feeding cycle:
Instruments
Similar to City water mode
V1 c
V2 c
V3 o
V4 c
V5 c
Pump not running
Display countdown timer
Duration syringe 40 s, rightmost instrument 5
s, following instruments 3 s each
Cleaning agent is fed to cup fill line
City Water Bottled Water
Feeding cycle:
Cup fill
Similar to City water mode
V1 c
V2 c
V3 o
V4 c
V5 o
Pump not running
Display countdown timer 4 s
Duration 4 s
