Chapter F - ADJUSTMENTS
Planmeca Compact i F-39
WMS OPERATION
Technical Manual
Cup fill+bowl rinse lines and instruments are flushed and hereafter bottle is filled. This is
repeated 4 times.
Countdown timer starts from 4 min. (4 x 1 min.). Timer is stopped during bottle filling.
City Water Bottled Water
Flushing cycle:
Cup fill + bowl rinse flushing
Similar to city water mode
V1 o
V2 o
V3 o
V4 c
V5 o
Pump running
Display timer
Duration 10 s (at same time bowl rinse, V6
open 3 s)
Flushing cycle:
Instrument flushing (each instrument 10 s by
turns, syringe all time)
Similar to City water mode
V1 o
V2 o
V3 o
V4 c
V5 c
Pump running
Display timer
Duration 50 s
Flushing cycle:
Bottle filling
Bottle has to be filled manually
V1 o
V2 o
V3 c
V4 c
V5 c
Pump running
Display wait He 65
Duration Until L1 reached
When cycle is completed
Display: He 36
