Planmeca Compact I User Manual

Chapter F - ADJUSTMENTS
F-38 Planmeca Compact i
WMS OPERATION
Technical Manual
Bottle filling and emptying is repeated 3 times to clean the bottle
City Water Bottled Water
Flushing cycle:
Bottle flushing, filling
Flushing cycle:
Bottle is filled manually
V1 o
V2 o
V3 c
V4 c
V5 c
Pump running
Display wait He 65
Duration Until L1 is reached
Bottle flushing, emptying Bottle flushing, emptying
V1 c V1 c
V2 c V2 c
V3 o V3 o
V4 o V4 o
V5 c V5 c
Pump not running Pump not running
Display 15, when L2 reached 15 s count-
down timer
Display wait, 15 s countdown timer
Duration until L2 reached + 15 s Duration until L2 reached + 15 s
Bottle is filled
City Water Bottled Water
Filling bottle Bottle is filled manually
V1 o
V2 o
V3 c
V4 o
V5 c
Pump running
Display wait He 65
Duration until L1 reached

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
