Chapter G - PARTS REPLACEMENT & REPAIR
G-6 Planmeca Compact i
UPHOLSTERIES REPLACEMENT
Technical Manual
c) Slide the attachment plates to their positions at the new seat upholstery backplate as shown
on the figure below.
d) Attach the new seat upholstery in reverse order.
Attachment plate
Attachment plate positions
