Chapter G - PARTS REPLACEMENT & REPAIR
Planmeca Compact i G-9
INSTRUMENT MULTIPLEXER RELATED
Technical Manual
l) Connect the instrument multiplexer cable to the connector P11 on the Instrument multiplexer
PCB.
m) Connect the water tube coming from the console arm to the T-nipple of the valve assembly.
Water tube from the
console arm
T-nipple
