Chapter C - SERVICE MODE
Planmeca Compact i C-11
GENERAL ABOUT THE SERVICE MODE
Technical Manual
n.98 Select how to freeze Intracam image from foot control 0 = pedal movement has no
effect
1 = pedal movement activates
door open/nurse call relay (video
printer freeze)
2 = pedal movement activates
serial communication w. Dimaxis
(default)
(pedal to the left = toggle freeze/
unfreeze image,
pedal to the right = save image)
3 = pedal movement activates
relay and serial communication
(1 + 2)
4 - 7 are the same as 0 - 3 but the
pedal operation is vertical.
C-37
n.99 Instrument hose flushing operation: disable HE 99 mes-
sage
0 = HE 99 is not displayed
(default)
1 = HE 99 will show, but does not
affect the unit functions
2 = HE 99 will show and the long
flushing must be performed.
C-38
n.100 Select dental unit type 0 = Prostyle Compact unit without
chair
1 = Prostyle Compact unit
2 = Prostyle Compact WE’S unit
3 = reserved for future use
4 = Planmeca Compact e
5 = Planmeca Compact i without
chair
6 = Planmeca Compact i
7 = Planmeca Compact e with
swivel position recognition
8 = Planmeca Compact i unit
without chair, connected to Plan-
meca Chair
9 = Planmeca Simulation Unit
---- = unit type not selected
C-38
n.101 Interrupt waterline cleaning operation 0 = normal operation (default)
1-6 = waterline cleaning opera-
tion on
C-38
n.102 Disable dry spray mode when using Plus Package 0 = dry spray mode enabled
1 = dry spray mode disabled
(Plus package signal tones)
2 = dry spray mode disabled
(Normal signal tones)
(default = 0)
C-39
Table 11: Other service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
