Chapter C - SERVICE MODE
C-10 Planmeca Compact i
GENERAL ABOUT THE SERVICE MODE
Technical Manual
n.84 Set type of extra assistant instrument 0 = no extra assistant instrument
1 = assistant’s syringe
2 = water operated saliva ejector
3 = assistant’s syringe and water
operated saliva ejector
4 = PM Starlight LED polymeriza-
tion light
5 = assistant’s syringe and PM
Starlight
6 = water operated saliva ejector
and PM Starlight
7 = assistant’s syringe, water
operated saliva ejector and PM
Starlight
C-35
Table 10: MCB CPU direct I/O related service modes (for factory use)
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
n 85 Show IC36 output signals ¦¦¦¦¦¦¦¦ C-35
n 86 Show IC37 output signals ¦¦¦¦¦¦¦¦ C-35
n 87 Show IC29 driver signals ¦¦¦¦¦¦¦¦ C-35
n 88 Show IC31 driver signals ¦¦¦¦¦¦¦¦ C-36
n 89 Show IC14 input signals ¦¦¦¦¦¦¦¦ C-36
n 90 Show IC16 input signals ¦¦¦¦¦¦¦¦ C-36
n 91 Show port A outputs (IC4) ¦¦¦¦¦ C-36
n 92 Show port A inputs (IC4) ¦¦¦ C-36
Table 11: Other service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
n.93 Adjustment of the duration of the spray water impulse 0 - 20, default = 1 C-37
n.94 Set syringe fibre optic light voltage 0 - 4 V, default = 3.7 V C-37
n.95 Set spray water impulse pressure 0 - 30, default = 15 C-37
n.96 RPM display / Enable low speed function for brush micro-
motors (Optional Plus package)
0 = RPM disabled / low speed
function disabled
1 = RPM disabled / low speed
function enabled
2 = RPM enabled / low speed
function disabled
3 = RPM enabled / low speed
function enabled
C-37
n.97 Set suction system cleaning time 0 sec. - 20 min, default = 2 min C-37
Table 9: Separator/suction system related service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
