Planmeca Compact I User Manual

Chapter C - SERVICE MODE
Planmeca Compact i C-9
GENERAL ABOUT THE SERVICE MODE
Technical Manual
Table 8: Patient chair related service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
n 75 Show emergency stop switch signal 1 = emergency stop plate acti-
vated
0 = normal
C-33
n.76 Show lift mechanism position sensor signal nnn C-33
n.77 Show backrest mechanism position sensor signal nnn C-33
n.78 Select S position function mode 0 = previous position remains in
memory when you drive from the
spit position to an automatic posi-
tion
(S key indicator light ON)
(default)
1 = previous position is cleared
from the memory when you drive
from the spit position to an auto-
matic position (S key indicator
light OFF)
C-33
n.79 Lift mechanism position sensor calibration mode L-_ turn axle counterclockwise
L-- ok
L-
–
turn axle clockwise
C-33
n.80 Backrest mechanism position sensor calibration mode b-_ turn axle counteclockwise
b-- ok
b-
–
turn axle clockwise
C-34
Table 9: Separator/suction system related service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
n 81 Show type of installed suction system 0 = Wet (or no) suction system
1 = Microvac II (Planmeca)
2 = Dürr Combisep
3 = Metasys
4 = Dürr VSA
5 - 7 = reserved
C-34
n.82 Set suction motor turn-off delay mm.ss = minutes.seconds
Cont = Continuously on
(default 00.03 = 3 seconds)
C-34
n.83 Set number of suction hoses / disable suction system 0 = no suction system in unit
1 = one suction hose only
2 = two hoses (default)
3 = three hoses (maximum)
C-34

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
