Planmeca Compact I User Manual

Chapter C - SERVICE MODE
C-8 Planmeca Compact i
GENERAL ABOUT THE SERVICE MODE
Technical Manual
n.69 Momentary spray mode / spray with foot control mode 0 = momentary spray water off,
instrument spray with foot control
on (default)
1 = momentary spray water on,
instrument spray with foot control
on
2 = momentary spray water off,
instrument spray with foot control
disabled
3 = momentary spray water on,
instrument spray with foot control
disabled
4 = momentary spray disabled,
instrument spray with foot control
on
5 = factory use
6 = momentary spray disabled,
instrument spray with foot control
disabled
7 = factory use
C-31
Table 7: Operating light related service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
n 70 Show operating light button signal 0 = button released
1 = button pressed
C-32
n.71 Set OP-light maximum voltage nn.n VAC (default 18.5) C-32
n.72 Disable OP-light automatic turn off/on with chair 1 = synchronized with chair
(default)
0 = completely independent
C-32
n.73 Disable OP-light automatic dimming with instrument con-
sole curing lights (not curing light in suction holder)
0 = completely independent
1 = automatic dimming, light
returns to initial brightness when
the polymerization cycle is
stopped (default)
2 = automatic dimming, light
returns to initial brightness when
an another instrument is selected
or operating light key is used.
C-32
n.74 Disable OP-light dimming function from its button 0 = dimmer function disabled
from OP-light push-button
1 = dimmer function enabled
(default)
2 = dimmer function disabled
from control panel button
3 = dimmer function disabled
C-32
Table 6: Foot control related service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
