Chapter D - HELP & ERROR MESSAGES
Planmeca Compact i D-9
ERROR MESSAGES
Technical Manual
OPERATING LIGHT RELATED
E56
OP-light is erroneously connected (bulb and push-button cross-connected). page D-19
E57
reserved
E58
Operating light bulb burned out page D-19
SEPARATOR SYSTEM RELATED ERROR MESSAGES
E59.n
The separator (only Dürr or Metasys) is reporting an functional error. page D-19
E60
The separator (only Dürr or Metasys) is not responding or the cable is faulty. page D-19
E61
The separator is flooded (only Microvac) with too much water. page D-19
E62
The newly attached separator is of unknown type. Please update the MCB
software.
page D-19
E63
WMS error page D-19
PATIENT CHAIR RELATED ERROR MESSAGES
E64
Seat position potentiometer or its cable is faulty or disconnected. page D-20
E65
Lift motor does not run or no signal from position sensing potentiometer. page D-20
E66
Lift motor or its position pot cable has a wrong connection. page D-20
E67
Backrest position potentiometer or its cable is faulty or disconnected. page D-20
E68
Backrest motor does not run or no signal from position sensing potentiometer. page D-20
E69
Backrest motor or its position pot cable has a wrong connection. page D-21
E70
reserved
E71
reserved
MCB CPU RELATED ERROR MESSAGES
E72.n
Software chip (EPROM or Flash-EPROM) error. page D-21
E73.n
CPU internal EEPROM error. page D-21
E74.n
RAM error. page D-21
E75.n
Program structure error. page D-21
E76
reserved
E77
Error in communicating with external serial device. page D-21
HEADREST RELATED ERROR MESSAGES
E80.n
Headrest error. page D-22
E81.n
Headrest communication error. page D-22
