Chapter 1-First Time Installation and Configuration
Polycom, Inc. 1-57
7 In the RMX Management pane, click the IP Network Services ( ) button.
8 In the IP Network Services list pane, right-click the Management Network () entry
and select Properties.
9 Enter the Control Unit IP, Shelf Management IP and Subnet Mask addresses in their
respective field boxes.
10 Click the Routers tab.
11 Enter the Default Router IP Address.
12 Click the OK button.
A Reset Confirmation dialog box is displayed.
13 Connect a workstation that is connected to the Management LAN to the RMX’s LAN 3
port.
14 In the Reset Confirmation dialog box, click Yes.
15 On the workstation that was connected to the RMX in Step 13, start the RMX Web Client
application:
a In the browser’s address line, enter the Control Unit IP Address in the format:
https://<Control Unit IP Address>.
b Press Enter.
16 Connect to the RMX. See "Connecting to the RMX” on page 1-42.
System restart may take up to five minutes.
