Application > Serial Matrix Setup > Auto LF
This option defines the printer action when print data is received past the
forms width setting.
Discards any data past the forms width.
Performs an automatic carriage return and line feed
when data is received past the forms width.
Application > Serial Matrix Setup > Define LF Code
This option controls the action of the printer when it receives a Line Feed
code (0A hex) from the host computer. If this feature is enabled, each time
the printer receives a line feed, it inserts an additional carriage return code
(0D hex) into the data stream. Do not use this feature if the host computer
sends carriage returns to the printer.
Does not insert a carriage return before each line feed.
The next print position will be the current print position
of the next line.
Inserts an extra carriage return before each line feed.
The next print position will be print position 1 of the
next line.
Application > Serial Matrix Setup > Control Code 06
Control Code 06 defines the function of ASCII code 06 hex (ACK). You can
select an alternate line spacing of 6.0, 8.0, or 10.3 LPI.
Application > Serial Matrix Setup > Overstrike
Overstrike determines the action required when a line is printed over a
previous line because a carriage return was received without a line feed.
Replaces the characters from the first line with the
second line.
Prints the second line on top of the first line making it
bolder.
