Media
Table 15. Media - General Information
Type
Roll-fed, die-cut continuous or fanfold labels, tags or tickets;
most direct thermal or thermal transfer materials.
Supply Roll
8 inch (203 mm) maximum diameter on 1.5-inch (37.5 mm) to
3-inch (76 mm) diameter cores.
Optional Internal
Rewinder
Accepts up to a 5-inch diameter roll of label backing.
Label Material
Thermal transfer plain-coated papers, vinyl, Mylar, metallized
paper, non-woven fabric, fine woven fabric, thermal-visible light
scannable paper, infrared scannable paper, thermal ticket/tag
stock, thermally-sensitive plastic stock.
Media Sensing
Horizontally moveable sensor assembly. When set to Mark, it
senses a black mark on the underside of tag or label stock. When
set to Disable, it senses no label indicators or ignores all existing
label length indicators on the installed media.
Label Taken Sensor (part
of the Peel/Rewinder
Option)
Detects when a printed label is at the printer exit throat. Used
only for Peel-Off Media Handling mode.
Label Peel-Off
Peels and presents label to the operator, one at a time. Automatic
Label Peel-Off is supported only when the internal rewinder is
installed. (The internal rewinder is a factory- or field-installed
option.)
