Printronix T6000 - Environmental; Physical; Acoustic Specifications

269
Environmental
Table 24. Environmental Information
Operating Temperature:
41° F to 104° F (5° C to 40° C)
Storage Temperature:
-40° F to 150° F (-40° C to 60° C)
Operating Humidity:
Storage Humidity:
20% to 85%, non-condensing
5% to 85% non-condensing
Ventilation:
Free air movement
Dust:
Non-conducting, non-corrosive
Physical
Table 25. Physical Dimensions
T6X04
T6X06
Outside Dimensions (in.)
12.3H x 10.97W x 20.3D
12.4H x 14.1W x 20.3D
Weight (lbs/kg)
31.9lbs. (14.5kg)
38.2lbs. (17.4kg)
Batch rewind: Add 1.75in D
ODV: Add 7.5in D and 6in H
Media Cutter: Add 1.4in D
Acoustic Specifications
Table 26. T6 Acoustic Noise Levels per ISO 9296
T6X04
T6X06
Printing @ 6 IPS
TBD dBA
TBD dBA
Standby:
Same as
Ambient
Same as
Ambient
