Printronix T6000 - Ribbon; Indicators and Switches

266
Table 16. Media Specifications
T6X04
T6X06
D
Media Length Range
Continuous/Batch Mode
Tear-Off Strip Mode
Peel-Off Mode
Cut Mode
0.25 in. (6.35mm) – 99 in. (2515mm)
0.25 in. (6.35mm) – 99 in. (2515mm)
1 in. minimum (25.4 mm) – 99 in. (2515 mm)
(1)
1 in. minimum (25.4 mm) – 99 in. (2515 mm)
These figures are approximate and depend upon the active emulation and application.
(1)
1.5 inch with Validator support.
Ribbon
Table 17. Ribbon Specifications
T6X04
T6X06
Ribbon Width Range
0.75-4.5 in.
19 -114.3 mm
2.0-6.8 in.
50.8-172.7 mm
Max. Ribbon Length
450m
450m
Max Ribbon Roll
Diameter
3.60 in.
3.60 in.
Indicators and Switches
Table 18. Indicators and Switches
Indicator Lights:
ONLINE
Switches:
POWER
Keys:
PAUSE, FEED, LEFT SOFT KEY, RIGHT
SOFT KEY, UP / DOWN / LEFT / RIGHT
ARROW KEYS,  (ENTER)
Message Display:
320 x 240 Color QVGA display
