Quantum Scalar i80 User Manual

Chapter 4: Configuring the Library
Working With LDAP User Accounts (Remote Authentication)
92 Quantum Scalar i40 and Scalar i80 User’s Guide
• User DN — The Fully Qualified Distinguished Name that contains
the users.
For an example, see Figure 14 on page 93
• Group DN — The Fully Qualified Distinguished Name that
contains the groups.
For an example, see Figure 14 on page 93
• Library User Group — The name of the group on the LDAP server
associated with library users who have user-level privileges (see
Privilege Levels on page 81 for more information on user
privilege levels). This group must exist on your LDAP server (see
LDAP Server Guidelines on page 89).
For an example, see Figure 14 on page 93
• Library Admin Group — The name of the group on the LDAP
server associated with library users who have administrator-level
privileges (see
Privilege Levels on page 81 for more information
on user privilege levels). This group must exist on your LDAP
server (see
LDAP Server Guidelines on page 89).
For an example, see Figure 14 on page 93
A sample of a completed dialog box is depicted below:

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
