Quantum Scalar i80 User Manual

Chapter 5: Advanced Reporting
Automatically E-mailing Advanced Reporting Reports and Logs
Quantum Scalar i40 and Scalar i80 User’s Guide 133
3 Under Select Reports, select the check box of the report(s) and
log(s) you want to send.
4 Under N
otification Day & Time, there are two drop-down lists.
From the first drop-down list, select the day of the week you want
to send the e-mail, or select Daily to send every day. From the
second drop-down list, select the time of day to send the e-mail
(hourly, using a 24-hour clock).
5 In the E-m
ail Address field, enter the recipient's e-mail address.
6 In the E-m
ail Comment field, enter a comment that will be sent in
the body of the e-mail (optional).
Note: Only letters, numbers, spaces and hyphens are allowed in
this fields. Do not use any special characters—like commas,
apostrophes to name a few.
7 Click Apply.
8 On the Success
window, click Close.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
