Chapter 9: Installing, Removing, and Replacing Components
Removing and Replacing the Front Bezel
254 Quantum Scalar i40 and Scalar i80 User’s Guide
d Repeat for all magazines in the library.
3 Prepare to
gain access to the bezel screws (see Figure 57 on
page 255 and Figure
58 on page 256 for locations). The method
depends upon how your library is installed. Follow the instructions
in the table below that
correspond to your library installation.
If your library is... Follow these steps...
Installed in a rack high enough
to
access to the bottom bezel
screws
Unscrew all the thumbscrews that secure the library to
the rack (the Scalar i40 has two thumbscrews; the
Scalar i80 has four). See Figure
58 on page 256.
Installed in a desktop kit Release the desktop cover by
removing two screws at
rear of the desktop cover, then slide the desktop cover
toward the back of the library two or three inches.
Installed very low in a rack so
that
you cannot access the
bottom bezel screws unless you
remove the library from the
rack
Remove the library from the rack (see
Removing the
Library From a Rack on page 243).
4 Slide
the library one-to-two inches forward out of the rack or over
the edge of the table or desk in order to access the two bottom
bezel screws.
WARNING: Only slide the library out far enough out to access the
two screws on the bottom of the library. The library is
not secured in the rack or on the desk. Pulling it out
too far could cause the library to slide out of the rack
or off the desk.
Caution: Ensure there is enough slack in the power cords and
cables connected in the rear of the library so that you
do not dislodge them when you slide the library
forward.
Caution: Do not tip the library or tilt it on its side.
