4. Sample measurements ABL800 FLEX Operator's Manual
4-26
Patient result messages
The Patient Result Messages screen is displayed after the Messages button has
been pressed.
Screen messages
The screen gives the erroneous parameter(s) and the message(s) with number(s)
referring to the message described in Troubleshooting Messages, chapter 11.
Messages can be seen on the following three information levels:
Level Explanation
User Messages for the user familiar with the basic daily operation of the
analyzer and primarily responsible for performing measurements.
Manager Messages for the user with deeper knowledge of the analyzer
functions and responsible for the analyzer's proper operation.
Service Messages for the service technician with thorough knowledge of
the operation and construction of the analyzer.
Buttons and
functions
The following buttons are available:
Button Function
Result
Press to return to the Patient Result screen.
Troubleshoot
Press to display the error description and operator actions – see
Troubleshooting Messages, chapter 11 for detailed information.
Print
Press to print the screen message(s).
Back
Press to return to the previous screen.
Note
Press to display the keyboard, type the note and confirm with
Enter.
If Notes for patient result were entered in the User-defined
Notes program (see chapter 3: Installation and Setup), select a
Note from the list with the up/down arrow buttons.
To edit a note use Edit Note and type the note on the keyboard.
Remember to confirm it with Enter on the keyboard.
To delete a note use Delete Note and delete it.
