13. Specifications ABL800 FLEX Operator's Manual
13-14
Analyzer specifications
Thermostatting
Solid state, 37.0 0.15 C
Spectrophometer Wavelength range: 478-672 nm
Hemolyzer
Hemolyzation: at approximately 30 kHz
cuvette light path: approximately 0.01 cm
External serial
ports
1 x RS-232 (9-pin) connector.
Baud rate: 1200, 2400, 4800, 9600, 14400, 19200, 38400,
115200
USB ports Pin header for two USB (Universal Serial Bus) ports
Ethernet 1 x RJ45 connector, 32-bit PCI bus interface, Novell NE
2000 compatible, onboard 10-Base T, fully compliant with
IEEE 802.3 10 Mbps CSMA/CD standards.
External printer
port
Bi-directional parallel (ECP/EPP/SPP) port (25-pin)
connector
Keyboard/Mouse Keyboard/PS/2 mouse interface
External VGA
Screen
Connector for VGA screen
Printer Built-in thermal; paper 11 cm wide
Barcode reader Built-in. Reading distance: contact – 70 mm.
Barcode length: max. 65 mm
Bar width: 127 m (5 mil)
Number of characters: <62
Code types: 128, 39, I 2 of 5
Class 1 laser product
Codabar barcode support
Dimensions (basic
module, without
accessories)
Height: 548 mm (21.95 in.) with the vertical screen
Width: 700 mm (27.6 in.)
Depth: 476 mm (18.5 in.)
Weight (kg)
(with AutoCheck)
ABL805:
ABL830/20/10:
ABL835/25/15:
ABL837/27/17
32.9
32.9
33.9
36.2
Continued on next page
