7. Replacements ABL800 FLEX Operator's Manual
Replacing inlet gasket unit and inlet probe
Replacing the
inlet gasket unit
To replace the inlet gasket, do the following:
Inlet gasket unit
Mount
Step Action
1.
Remove the capillary and then the syringe inlet flaps and record the
action in the Hold mode.
2.
Remove the old inlet gasket unit by grabbing it on either side and
lifting it upward.
3.
Slide the new inlet gasket unit onto the mount and press down the top
of the unit to secure it in place.
Mount the syringe inlet flap and then the capillary inlet flap.
4.
Press Restart.
To replace the inlet probe, do the following:
Replacing the
inlet probe
A
ttachment
and clip
Tube
Inlet
probe
Step Action
1.
Remove the inlet flaps to enter the Hold mode.
2.
Remove the gasket unit – see Replacing the inlet gasket unit above.
3.
Lift the clip to open it.
4.
Lift the inlet probe out of the attachment.
Continued on next page
7-12
