Placing Originals
11
2
Placing Originals
You can place the originals either in
the optional ADF or ARDF or on the
exposure glass. Some types of origi-
nals are unsuitable for the ADF or
ARDF, so they must be placed on the
exposure glass.
Place to scan by portrait orientation
for the original of A4, 8
1
/
2
"Ă—11" or
larger size, landscape orientation for
the original of A4, 8
1
/
2
"Ă—11" or small-
er size shown in the illustration. The
size of some originals might not be
detected. For details, see p.15 “Origi-
nal sizes difficult to detect”.
âť–
âť–âť–
âť– How to place A4, B4 JIS (Japanese
Industrial Standard), A3, 8
1
/
2
"Ă—
Ă—Ă—
Ă—11",
8
1
/
2
"Ă—
Ă—Ă—
Ă—14", and 11"Ă—
Ă—Ă—
Ă—17" size originals
Note
âť’ When you place originals as
shown in the above illustration,
the fax header will be printed on
the received faxes at the destina-
tion as follows:
• *1 On the top of the fax
• *2 On the left side of the fax
âť–
âť–âť–
âť– How to place A5, 5
1
/
2
"Ă—
Ă—Ă—
Ă—8
1
/
2
" and B5
JIS size originals
Limitation
âť’ If you place A5, 5
1
/
2
"Ă—8
1
/
2
" or B5
size documents on the exposure
glass, they will not be detected. A5,
5
1
/
2
"Ă—8
1
/
2
" or B5 size documents
placed in the ADF or ARDF are
sent. See p.15 “Original sizes diffi-
cult to detect”.
Note
âť’ When you place originals as
shown in the above illustration,
the fax header will be printed on
the received faxes at the destina-
tion as follows:
• *1 On the top of the fax
• *2 On the left side of the fax
• *3 When the scanning size is set
to A4L or 8
1
/
2
"Ă—11"L on the
original size specifying display.
Original
*1
*2
Where original is placed
Exposure glass For ADF or ARDF
AAN055S
Original
*2 *3
*1
Where original is placed
Exposure glass
For ADF or ARDF
AAN056S
Kir-C2-AEcombine_F_FM.book Page 11 Monday, September 29, 2003 11:36 AM
