Ricoh Aficio SG 3100DN User Manual

5. Each part of the paper feed roller has a hook on it. They are locked when their hooks are engaged
in the rod's grooves. Unhook the parts and slide them to remove from the rod.
Remove the paper feed roller's fixing pin [A].
6. The paper feed roller.
Rollers
123
