2. Remove harnesses from the harness guide ( x 3, x 1).
• It is easier to unhook harnesses from front to rear side of the machine (the direction pointed by
the blue arrow in the upper photo).
•
Remove the bypass drawing connector before removing the harnesses when it is difficult to
remove them from the harness guide.
3. The vertical encoder wheel protection cover [A] ( x 2).
4. Replacement and Adjustment
76
