Order No.
35 MHz: F 8042
40 MHz: F 8043
41 MHz: F 8044
FX-30
17
4
. Function sequence for Helicopter use
H1 + 2, HE3 90°, HR3 120°
HN3 120°, H3 140°
1 Throttle Throttle
2
Rudder Rudder
3 Gyro Aileron
4 Aileron Elevator
5 Elevator Pitch
6 Pitch Elevator 2
7 Governor Gyro
8 Governor 2 Governor
9 Needle Governor 2
10 AUX 3 Needle
11 AUX 2 AUX 2
12 AUX 1 AUX 1
VC1 AUX 1 AUX 1
VC2 AUX 1 AUX 1
VC3 AUX 1 AUX 1
VC4 AUX 1 AUX 1
CH Heli 4
NOTE!
All model types are available when twelve-channel PCM-G3
mode is selected.
If you select FM 8-channel or PCM 1024, the number of avai-
lable model types is reduced. In this case only the model
types shown with a grey background are available.
VC 1 … 4 are virtual functions without physical receiver out-
puts; however, these functions affect multiple servos.
5.5
