SatLab SLT2 - Page 145

Total Station Manual
-
144
-
○
2
In [Define Ref-ARC
method] screen, press
the [F2] or the numeric
key [2] to choose the
[Start&End Pt, Angle ],
and measure start point.
[F2]
or
[2]
③ There are several
method to obtain the
first point for baseline
definition
A: Enter point name,
then press [F1](ALL) to
define start point.
Input point name
+
[F1]
A: Get the target point by measure.
B: Input point name,
press [F2](DIST) +
[F3](REC) to save target
point , the saved result
will be directly put into
calculation.
[F2]
+
[F3]
B: Get the target point by DIST+REC.
C: Input point name,
press [F4](↓ ) to shift to
subscript function, press
[F1](Find) to check if this
point exists, if not exist,
then should firstly input
or measure this point's
coordinate.
Input point name
+
[F4]
+
[F1]
+
[F4]
C: Input the name of the point and
find whether it is in memory.
D: Press [F2](List) , in
[Find Pt.] screen, search
[F2]
+
D: Select the point by list in the
instrument.
