Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26

Communication interfaces

4-17

Serial interfaces on socket A

4.6.4 Current loop with PCD7.F130, Port #1 (without PCD1.M110)

PCD7.F130:

TTY / current loop 20 mA (active or passive),

for socket A

Connections

PCD7.F130

Socket A

Screw terminal block, socket A

Saia PCD

active

Transmitter

Receiver

Transmitter

PCD7.F130

(active)

Cable

Peripheral

(passive)

Pin-Nr.
