SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
4
Communication interfaces
4-10
Onboard interfaces
4.5.5 RS-485 communiaction interface PORT # 6, only on PCD2.M480
On the PCD2.M480, on Port #6, is a built-in RS-485 interface.
29
27
26
25
24
23
22
21
20
D
/D
WD
WD
PCD2.M480
RX - TX
/RX - /TX
28
RS-485
Bus-cable
Screw terminal block
O
C
Choice of the termination resistors
PCD2.M480
Port #6
PCD1.M1xx
PCD2.Mxx0
PCD1.M1xx
PCD2.Mxx0
PCD1.M1xx
PCD2.Mxx0
/RX - /TX
n n
n
/n
/n/n
RX - TX
+5 V
29
28
+5 V
Pull up
330 Ohm
Termination
Resistor
150 Ohm
Segment length max. 1200 m
max. 32 stations
Bus RS-485
First station Middle stations End station
Pull down
330 Ohm
At the rst and last stations, the jumper must be set to the “C“ (closed) position.
At all other stations, the jumper must be set to “O” (open) position (factory setting).
