SBC PCD1 Series User Manual

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
Appendix
A-12
Order codes
A
Type Description Weight
Digital input modules
PCD2.E110 24 VDC, input delay typically 8 ms (pulsed voltage possible) 35 g
PCD2.E111 24 VDC, input delay typically 0.2 ms (smoothed voltage required) 35 g
PCD2.E112 12 VDC, input delay typically 8 ms (pulsed voltage possible) 35 g
PCD2.E116 5 VDC, input delay typically 0.2 ms (smoothed voltage required) 35 g
PCD2.E160 24 VDC, input delay typically 8 ms
(pulsed voltage possible, connection via 34-pole system cable)
25 g
PCD2.E161 24 VDC, input delay typically 0.2 ms
(smoothed voltage required, connection via 34-pole system cable)
25 g
PCD2.E165 24 VDC, input delay typically 8 ms
(pulsed voltage possible, connection via 20-pole spring terminal block)
30 g
PCD2.E166 24 VDC, input delay typically 0.2 ms
(smoothed voltage required, connection via 20-pole spring terminal block)
30 g
Digital input modules, electrically isolated
PCD2.E500 110 … 240 VAC, input delay typically 10 ms (electrically isolated) 55 g
PCD2.E610 24 VDC, input delay typically 10 ms (pulsed voltage possible) 40 g
PCD2.E611 24 VDC, input delay typically 1 ms (smoothed voltage required) 40 g
PCD2.E613 48 VDC, input delay typically 10 ms (pulsed voltage possible) 40 g
PCD2.E616 5 VDC, input delay typically 1 ms (smoothed voltage required) 40 g
Digital output modules
PCD2.A300 with 6 outputs 24 VDC / 2 A 45 g
PCD2.A400 with 8 outputs 24 VDC / 0.5 A 40 g
PCD2.A460 connection via 34-pole system cable 30 g
PCD2.A465 connection via 24-pole spring terminal block 35 g
Digital output modules, electrically isolated
PCD2.A200 with 4 make contacts 2 A / 250 VAC or 2 A / 50 VDC 60 g
PCD2.A210 with 4 break contacts 2 A / 250 VAC or 2 A / 50 VDC 60 g
PCD2.A220 with 6 make contacts 2 A / 250 VAC or 2 A / 50 VDC 65 g
PCD2.A250 with 8 make contacts 2 A / 48 VAC or 2 A / 50 VDC 65 g
PCD2.A410 with 8 outputs 24 VDC / 0.5 A, electrically isolated 40 g
Combined digital input and output module
PCD2.B100 with 2 inputs and 2 transistor outputs, plus 4 selectable as inputs or outputs 45 g
Multi-functional I / O modules
PCD2.G400 10 digital inputs,
2 analogue inputs 10 bit,
6 analogue inputs 10 bit Pt / Ni 1000,
8 digital outputs,
6 analogue outputs 8 bit
79 g
PCD2.G410 16 digital inputs,
4 analogue inputs 10 bit,
4 relay outputs,
4 analogue outputs 8 bit
79 g
