Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-7
Overview
5.1.3 Power consumption of PCD2 input/output modules
Type
PCD2.…
Maximal
internal current
consumption
I from +5 V [mA]
Maximal
internal current
consumption
I from +V [mA]
Maximal external current
consumption
at 24 V, I [mA]
E11x
E16x
E500
E61x
24
72
1
24
--
--
--
--
8 inputs, 6 mA/input
16 inputs, 4 mA/input
6 inputs, 10 … 12 mA/input
8 inputs, 5 mA/input
A200
A220
A251
A300
A400
A410
A46x
B100
15
20
25
20
25
24
74
25
--
--
--
--
--
--
--
--
32 mA
1)
48 mA
1)
64 mA
1)
Load current
Load current
Load current
Load current
Load current
W200/210
W220
W300/310
W3x5
W340/360
W350
W4x0
W5x0
W525
W600
W605/625
W610
W615
W720
W745
8
8
8
60
8
8
1
200
40
4
110
110
55
60
200
5
16
5
0
20
30
30
--
--
20
--
--
--
100
--
--
--
--
--
--
--
W410 100 mA
2)
--
Load current
--
--
100 mA
2)
90 mA
--
--
H100/H110
H150
H210
H310/H311
H320/H322
H325/H327
90
25
85
140
230
250
--
--
--
--
20
20
CCO output: load current
Load current
Load current
max. 15 mA
Load current
Load current
1) Coil resistance of the relay 3 kOhm
2) Basic consumption 20 mA, plus 0..20 mA per output
5.1.4 Maximal current consumption from base units
Base unit
internal 5 V-Bus internal +V-Bus
PCD1 750 mA 100 mA
PCD2.M110/M120 (before hardware version H) 1100 mA 200 mA
PCD2.M110/M120 1600 mA 200 mA
PCD2.M150/M170 1600 mA 200 mA
PCD2.M480 2000 mA 200 mA
