Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
Document History
Content
0-7
0
0.1 Document History
Date Version Changes Remarks
EN11a 2004-12-24 Whole Doc.
Chapt.
4.8.1
Page 57
- translation from D11
-errorinProbus:4.8.1new
- error in formulas: Page 57
EN12 2005-02-01 Chapt. 0
Chapt. 1
Chapt. 3
- error in index (Acrobat)
- error in graphical index M480
- watch-Dog IL-Example.: new
EN13 2005-10-11 Chapt. 5 - corrected error in pin allocation PCD2.A465
EN14 2007-07-25 Chapt. 3
Chapt. 4
Chapt. 5
Chapt. A
- inserted new controllers PCD1.M1x5
- added communication modules PCD7.F121
and PCD2.T500
- new order for the I/O-modules, according to
the price list
- maximal current of the I/O-modules instead of
typical current.
- added new I/O-Modules PCD2.E112,
PCD2.E116, PCD2.E613, PCD2.E616
- PCD2.A465 pinout corrected
- new TIP by PCD2.W2x0, wrong polarity on
input
- description of the Jumper positions for
PCD2.K525
- calculation of the spark deletion in the appendix
EN15 2008-07-22 Chapt. 5
Chapt. 5
- Added new module PCD2.W525
-«Denitionofinputsignals»revised
EN16 2008-12-17 Chapt. 3.4
Chapt. 5.7
Chapt.
5.12.1
Chapt. 6
Chapt. 7.1
- PCD2.M150 now with FW update
- Wiring PCD2.W2x0 corrected
- Digital / analog values PCD2.W2x0 correc-
ted
- New in its own handbook 26/792
- New indication for battery change
EN17 2009-12-15 all Conversion in CS4 and error correction
EN18 2010-02-15 Chapt. 3 New chapt. 3.12/3.13
EN19 2011-01-05 Chapt. 4 PCD7.F121 for all CPU types other than
PCD1.M110
EN20 2011-06-01
2011-11-23
Chapt. 3 -5
Chapt.
4.1.2.
Chapt. 3-19
- External and 24V power supply of the
modules, PGND assignments
Use of SBC S-Bus
Correction HW watchdog error.
EN21 2012-03-29
2012-06-20
Chapt. 3
Chapt.
5.2.1
Chapt.3
Minimal storage temperature -20 °C ➞ -25 °C
PCD2.E112 not PCD2.E113
User memory HW version <H
EN22 2013-04-23 Chapt. 4 internal wiring PCD2.K111
EN22 2013-11-26 - updated
